Preparation Work
Tools Preparation
- Prepare various types of wrenches, screwdrivers, pliers, etc. as basic tools for disassembling and installing screws, nuts, and pins and other components; if the Chains are fixed by a special connection method, additional special tools (such as Chains disassembler) should be prepared.
- Prepare new Chains that are exactly the same as the original Chains in model and specification to ensure that the pitch, width, strength grade, etc. of the Chains are consistent, ensuring a good fit between the new Chains and the equipment Rollers and other components.
- Prepare protective gloves, goggles, etc. as personal protective equipment to ensure personal safety during operation.
Equipment Shutdown And Cleaning
- Completely shut down the Apron Feeder, cut off the power supply, and hang a warning sign at the power switch stating "Under Maintenance, Do Not Close Switch" to prevent accidental startup of the equipment and potential safety accidents.
- Clean the residual materials on the feeder, remove all the remaining materials from the feed inlet and outlet to avoid hazards caused by falling materials during the replacement of Chains; at the same time, perform a simple cleaning of the equipment to facilitate observation and operation of each component.
Disassembly Of The Old Chains
Loosen The Tensioning Device
- Locate the tensioning device of the Apron Feeder (usually on the side of the Chains). Follow the type of the tensioning device to operate:
- Spiral tensioning device: Use a wrench to rotate the screw counterclockwise to gradually loosen the tension of the Chains;
- Weight-based tensioning device: Raise or fix the weight appropriately to reduce the tension of the Chains.
- During the loosening process, closely observe the degree of Chain slack to avoid over-loosening and causing the Chains to fall off.
Remove The Chain Connection Components
- According to the connection method of the Chains, remove the pins, bolts, or other connecting parts of the chain sections: For pin connections, use pliers to pull out the pin; for bolt connections, use a wrench to unscrew the bolt; during the removal process, properly store all small parts to prevent loss.
- For longer Chains, they can be disassembled in multiple sections. Usually, start from one end of the Chains and remove section by section until the entire old Chains are removed from the equipment.
Installation Of The New Chains
Initial Installation Of The New Chains
Align one end of the new Chains with the device Rollers, ensuring that the chain links are correctly inserted into the Rollers' teeth grooves. If there is a guiding device, place the Chains in the guiding slot.- Use connecting components (screws or bolts) to securely fix the initial part of the new Chains to the original connecting part of the device Chains. Ensure that the screws and bolts are installed properly and install the opening pins and other anti-loosening devices.
Gradual Installation Of The Remaining Parts
- Along the Rollers and the device track, gradually wrap the new Chains around the Rollers, connecting the chain links section by section. During the installation process, you can manually rotate the Rollers to assist in positioning the Chains correctly.
- Ensure that each section of the Chains is installed correctly, with the chain links tightly connected, without any looseness or misalignment. For longer Chains, multiple people need to collaborate during the installation process, checking the meshing between the Chains and the Rollers while installing to avoid jamming and skipping teeth.
Adjustment And Inspection
Adjustment Of Tensioning Device
- After the new Chains are installed, re-adjust the tensioning device to ensure that the Chains are at the appropriate tension:
- For the spiral tensioning device: Rotate the screw clockwise gradually to increase the tension of the Chains;
- For the weight-based tensioning device: Place the weight back in its original position and let it automatically tension the Chains.
- Tensioning Standard: The Chains should have appropriate elasticity during operation, without excessive slack or tightness; manually rotate the Rollers to check the tightness, and generally, the sag of the Chains on the Rollers should not exceed 2%-3% of the pitch of the chain links.
Inspection Of Chains Operation
- After the adjustment is completed, manually or point-drive the motor at a low speed to allow the Chains to run slowly, observe whether the Chains can run smoothly on the Rollers and the track, and check for any abnormal sounds or jamming phenomena.
- Check the meshing between the Chains and the Rollers to confirm that the chain links are securely connected; if any problems are found, immediately stop the machine for inspection and adjustment until the Chains run normally and smoothly.
Comprehensive Inspection Of Equipment
Conduct a comprehensive inspection of the equipment as a whole to confirm that all components are installed properly and securely, without any missing parts; clean the surrounding debris of the equipment, remove the warning signs at the power switch, prepare to test-run the equipment, and ensure that all replacement work is completed.
