Bucket Elevator

Bucket elevator is a lifting device that carries bulk materials vertically. The bucket elevator loads materials at the tail for lifting operations and discharges at the head. The loading material form is cut and take and inflow type; Unloading material form for centrifugal, gravity or centrifugal and gravity two combined forms of three kinds of unloading. According to the different traction components, we can be divided into belt bucket lifting machine and chain bucket lifting machine. These two bucket lift machines are respectively used in different industries. According to different materials can be bucket lifting machine shell production of carbon steel and stainless steel. Bucket lifting machine is widely used in cement, building materials, power plant, food factory, chemical industry and other industries.

In general, the material form directly decide the material discharging mode, common rules for powder material using centrifugal mass ejection by gravity discharge, discharge, block material and the different methods of discharging hopper of bucket elevator adopted in the form of different, centrifugal mass ejection unloading much use shallow and curved fights, and gravity discharge with deep. The type of hopper used by the bucket lifting machine is different, and the conveying capacity of the material is different in unit time. The final conveying capacity of bucket elevator depends on the hopper form, hopper speed, material proportion, material nature, a comprehensive parameter of hopper quantity.

































• Stable and reliable operation, low noise, convenient maintenance.
• Box body stamping forming, the middle box body four reinforcement, the use of full welding, lifting pipe with bite structure, eliminate dust leakage, the overall rigidity and sealing is strong.
• Traction member adopts plate sleeve roller chain, and after carburizing quenching treatment, with high tensile strength and wear resistance.
• Environmental protection and energy saving, not only can improve the general powder, granular and massive materials, but also can improve the grinding and cutting of large materials.
• Operating tube is fully open structure, so that detection, operation and maintenance is convenient, less wearing parts, low use cost.
• The cushion device is added to the machine base, which can reduce vibration and prevent the sudden increase of lifting amount or large foreign matter from breaking the dustbowl belt. At the same time, the tension force of the dustbowl belt can be automatically adjusted within a certain limit
• Optional check mechanism, when the height is higher (> 20 meters) can prevent material backfilling caused by elevator blockage
• The head wheel is coated with glue, which can effectively prevent the dustbowl belt from slipping and running away, and reduce power consumption. Tail drum adopts squirrel cage, which can effectively solve the problem of material blocking.



























EXCT is committed to open-pit mining (coal industry, oil shale, etc.) crushing and screening production system, EPC general contract construction and production and operation services, as well as large crushing equipment, screening equipment, conveying equipment, feeding equipment, environmental protection equipment and other special equipment research and development, manufacturing, sales and service as one of the modern high-tech enterprises.

We have more than 60 national patents and have received provincial and ministerial scientific achievement certifications. Our core products have attained performance metrics that meet leading international standards, earning multiple national and provincial technology awards.

We create value for global mining customers through advanced process technology, enhancing operational reliability, efficiency, and precision. Leveraging sophisticated equipment and deep industry knowledge, we innovate across material crushing, screening, conveying, dust removal, storage, and automation systems. Our service system offers one-stop professional support throughout the project lifecycle-from engineering consulting and scheme design to equipment production, installation, commissioning, spare parts supply, and operational support.

Aligned with evolving global economic trends, we are building an international presence focused on technological and service innovation. We cultivate versatile talent and experienced service teams to strengthen our competitiveness in the international market, delivering high-value solutions that support the advancement of national industries worldwide.













Why choose us?

• Our Bucket Elevator products are designed to maximize production efficiency and minimize downtime.
• To seek innovation by technology, to seek development by reputation, to seek survival by quality, to promote brand by service, and to take customers as friends are our business realm.
• Our Bucket Elevators are designed with safety in mind and adhere to all relevant safety standards.
• Our Bucket Elevator are the first to have core competitiveness in both domestic and foreign markets.
• We use only the finest materials and components to manufacture our Bucket Elevators, ensuring durability and long-lasting performance.
• We will continue to act in the interest of our customers and continue to introduce new Bucket Elevator that meet the needs of the market and ensure leadership in the industry.
• As a reputable manufacturer, we are committed to using only the best materials and components.
• We have won praise from our customers with high quality, large quantity, reasonable price, timely delivery, and legal operation.
• Our Bucket Elevator products are shipped to you with all the necessary hardware and installation instructions for easy installation.
• Our primary objective is usually to offer our shoppers a serious and responsible small business relationship, offering personalized attention to all of them for Bucket Elevator.
